See the Difference

Our clearest sonar ever, Active Imaging™ HD delivers the highest-definition views of Lowrance® CHIRP, SideScan and DownScan Imaging™. Experience a new level of clarity and improved target separation with extremely detailed views of fish and fish-holding structure like rockpiles, standing timber, weedbeds, ditches, drop-offs and more.

FishReveal™

Get the best of Lowrance® CHIRP sonar and DownScan Imaging™ on one screen with the FishReveal DownScan view, a Lowrance exclusive that helps you easily recognize fish from structure and cover on high-detailed DownScan images.

Designed for Clarity

The Active Imaging™ HD transducer not only delivers three key sonar technologies – Lowrance® CHIRP, SideScan and DownScan Imaging™ – in one convenient package, but also features a new transducer design that boosts signal clarity.

Transducer Options Available:
•ActiveImaging HD 3-IN-1
•ActiveImaging HD 2-IN-1
•ActiveImaging HD 3-IN-1 Fish Reveal M/W *requires S3100 module
•ActiveImaging HD 3-IN-1 Fish Reveal HW *requires S3100 module
•ActiveImaging HD 3-IN-1 Ghost Nosecone

•Active Imaging HD allows for supporting Lowrance users to select the desired frequency for Side and Down separately so the angler can pick the right range/resolution for the desired view.

SideScan Frequencies Low CHIRP Freq. : 455 kHz (445-495 kHz)
High CHIRP Freq. : 1075 kHz (1065-1115 kHz)

DownScan Frequencies Low CHIRP Freq. : 700 kHz (690-740kHz)
High CHIRP Freq. : 1200 kHz (1190-1240 kHz)

Side/Down Independently Selectable Freq. Yes, Independently mix-and-match side and down frequency ranges to get the picture that you want
Range Max 150ft range at High Frequency
Max 300ft range at 455 (Low Frequency)

Compatible Displays Direct connect to: HDS Pro
Ethernet connect to via S3100: HDS Live, EliteFS
